DiaStream® iQ, HD-System
| B. Braun- Home
DiaStream® iQ, HD-System
7211125DiaStream® iQ, HD-System
- Produkttyp
- A/V Sets
- Applicable machine
- B.Braun - Dialog iQ
- Features
- Farbkodierte Patientenklemmen, art. POD for PA, ML/FL single packed, art. POD for PBE
- Füllvolumen
- 121 ml
- Arterial volume
- 61 ml
- Venous volume
- 60 ml
- Inner-ø Pump segment
- 8.00 mm
- Inner-ø Bloodline tubing
- 4,3/4,8 mm
- Inner-ø Heparine line
- 1.50 mm
- ø Venous chamber
- 22 mm
- Produkt enthält PVC
- Ja
- Produkt enthält Latex
- Nein
- Produkt enthält DEHP
- Nein
- Sterilität
- steril
- Sterilisationsart
- Radiation
- Einmalgebr./Wiederverwendbar
- Einwegartikel
- Storage Environment Temperatur
- 0 °C - 30 °C
