Certofix® Mono S 220 | B. Braun4160207-07Certofix® Mono S 220
- Markenname
- Certofix®
- Produktname (HC)
- Certofix® Mono
- Produkttyp
- Zentraler Venenkatheter
- Einführtechnik
- Seldinger (Seldinger Kanüle)
- Venenzugang
- subclavia, axillary, jugularis
- Kathetermaterial
- PUR
- Anzahl der Lumina
- 1
- French F (Katheter)
- 4.0 Fg
- Katheterlänge
- 20.0 cm
- Länge (Inch)
- 8"
- Aussen-ø Katheter (metr.)
- 1.40 mm
- Länge des Führungsdrahtes
- 50.0 cm
- Aussen-ø des Führungsdrahts
- 0.630 mm
- mit knickstabil. Führungsdraht
- Ja
- Gauge (distal)
- 18
- Innen-ø Katheter (metr.)
- 0.80 mm
- Füllvolumen (distal)
- 0.32 ml
- Durchflussrate (distal)
- 18 ml/min
- Gauge (medial 1)
- -
- Gauge (medial 2)
- -
- Gauge (medial 3)
- -
- Gauge (proximal)
- -
- Kanülentyp
- Seldinger
- Gauge (Kanüle)
- 20
- Außen-ø Kanüle (mm)
- 0.90 mm
- Kanülenlänge (mm)
- 50 mm
- Länge der Kanüle (inch)
- 2"
- Aussen-ø Schlauch
- 1.95 mm
- Innen-ø Schlauch
- 1.30 mm
- Schlauchlänge
- 135.00 mm
- EKG-Kabel
- Ja
- beiliegender Konnektor
- Nein
- mit Skalpell
- Nein
- mit Spritze
- 5 ml
- Art der Verpackung
- Peel pack
- Prod. (unverp.) enthält PVC
- Nein
- Prod. (unverp.) enthält Latex
- Nein
- Prod. (unverp.) enthält DEHP
- Nein
- Produkt enthält PVC
- Nein
- Produkt enthält Latex
- Nein
- Produkt enthält DEHP
- Nein
- Verpackung enthält PVC
- Nein
- Verpackung enthält Latex
- Nein
- Produkt enthält Nickel
- Ja
- Einmalgebr./Wiederverwendbar
- Einwegartikel
- Sterilität
- steril
- Sterilisationsart
- EO
- Antimikrobieller Katheter
- nicht-beschichtet
- High Flow Sets
- Nein
- Safety Sets
- Nein
- Paed Sets
- Nein
